特製高亮鋁質標簽 , 比鑽石更耀眼
HD910A 1.0.3.2+1.0.2.6 雙核心操作影片
| 功能 / 型號 |
HD910A
|
HD900A
|
HD900B
|
晶片組
|
Realtek 1186
|
Realtek 1186
|
Realtek 1186
|
記憶體
|
512MB DDR3
|
512MB DDR3
|
512MB DDR3
|
Nor Flash
|
2MB
|
2MB
|
2MB
|
Flash容量
|
2GB
|
4GB |
4GB
|
有線網路
|
100M
|
1000M
|
1000M
|
USB 2.0
|
Yes x 1
|
Yes x 2
|
Yes
|
USB 3.0 Host
|
Yes x 1
|
No
|
Yes
|
USB 3.0 Device
|
No
|
No
|
Yes
|
PCIE WIFI
|
802.11N
|
802.11N
|
802.11N
|
內置3.5硬碟抽取盒
|
No
|
No
|
Yes
|
| 內置風扇 | Yes | No | Yes |
BD LOADER
|
No
|
No
|
Yes
|
裸接供電SATA
|
Yes
|
Yes
|
Yes
|
CVBS
|
Yes
|
Yes
|
Yes
|
YPbPr
|
Yes
|
Yes
|
Yes
|
HDMI 1.4
|
Yes
|
Yes
|
Yes
|
L/R stereo Audio
|
Yes
|
Yes
|
Yes
|
Spdif output
|
Yes
|
Yes
|
Yes
|
Coxial Spdif output
|
Yes
|
No
|
Yes
|
CARD Reader
|
MS/MMC/SD
|
MS/MMC/SD
|
MS/MMC/SD
|
VFD 顯示屏
|
No
|
No
|
Yes
|
面版按紐
|
No
|
No
|
Yes
|
MCU電源管理
|
Yes
|
Yes
|
Yes
|
| HD910A / HD900A 差異說明
NAND FLASH主要是做為 軔體存放空間 海美迪1186 軔體約為 200MB 瀏覽器 Cache 約 250MB Android Data 內建APK約為50MB , HD900A刷機後剩餘 可安裝APK空間為 3.5GB HD910A刷機後剩餘 可安裝APK空間為 1.5GB 這部份使用上不會有差異 , 用不了500MB的軟體 有線網路 100MB / 1000MB 的差別 , 100MB 區網最高約跑 110M~130M 1000MB 區網最高約跑 130M~170M 兩者差異也不大 |
|||
| 卡巴熊 HD910A 內容 HD910A X1 IMS遙控器 X 1 12V 2A電源 X 1 WIFI天線 X 1 原廠HDMI 1.3b X 1 SATA 7+15線 X 1 操作手冊 X 1 保固卡 X 1 提供論壇及軔體服務 保固一年 |
|||
| HiMedia HD910A | |
| *真正的藍光3D解密 , 非2D轉3D *支援原生36bit色彩 |
|
| Brand | HiMedia |
| Model | HD910A |
| Max Resolution | 1080p [Full-HD] |
| Chipset Model | Realtek 1186 |
| Chipset Mhz | 750 |
| Memory | 512MB DDR3 2Gbit Flash |
| Operating System | Realtek SDK4 / Android 2.2 MIPS |
| USB (Host) | 2 |
| USB Version | 2.0 |
| SD/MS/MMC | 1 |
| Other Storage | External SATA |
| File Systems | FAT, EXT3, NTFS |
| UPnP | Yes |
| DLNA | Yes |
| Network Protocols | Samba, NFS |
| Wired Network | 100M Ethernet |
| Wireless Network | Wi-Fi(n) |
| HDMI | 1 |
| Component Video | 1 |
| Composite Video | 1 |
| HDMI Version | 1.4a 3D |
| Stereo L/R Audio | 1 |
| S/PDIF TOSLink | 1 |
| Video Formats (Codecs) | MPEG1/2/4, WMV9/VC1, DivX, H.264, AVC, RM/RMVB, Adobe SWF |
| Video Extensions (Containers) | MTS, M2TS, TS, TP, MKV, AVI, WMV, MPG, MOV, VOB, MP4, FLV, IFO, BD ISO/Folder, DVD ISO/Folder, CSS |
| Audio Formats (Codecs) | MPEG1 Layer 1/2/3, MPEG2 Layer 1/2, MPEG2/4 LC-ACC, FLAC, AC3, DTS, DTS-HD, LPCM, RA1/RA-Cook/RA-lossless, OGG, APE |
| Image Formats | JPEG, GIF, BMP, PNG and TIFF |
| Subtitle Formats | SRT, SMI, SUB, SSA, IDX + SUB, PGS, DVDSUB, VOBSUB, MKV Inner subtitle |
| 3D SBS | Yes |
| 3D Top Bottom | Yes |
| 3D Frame Packing | Yes |
| 3D Frame Sequential | No |
| Blu-Ray 3D | Yes |
| DVD ISO | Yes (original menus) |
| Blu-Ray ISO | Yes. BD Profile 1 + BD-Lite (original menus) |
| Dolby Digital Downmix | Yes |
| Dolby Digital Passthrough | Yes |
| Dolby Digital Plus Downmix | Yes |
| Dolby Digital Plus Passthrough | Yes |
| Dolby TrueHD Downmix | Yes |
| Dolby TrueHD Passthrough | Yes |
| DTS Downmix | Yes |
| DTS Passthrough | Yes |
| DTS-HD HR Downmix | Yes |
| DTS-HD HR Passthrough | Yes |
| DTS-HD MA Downmix | Yes |
| DTS-HD MA Passthrough | Yes |
| Internet Radio | Shoutcast |
| Web Services | Loads |
| Bittorrent | Yes |
| Web Browser | Yes |
| PPS | NO |
| HiMedia HITV 2.0 | Yes |
| Xunlei P2P Video | NO |
| Qlive streaming | NO |
| Skype | Yes |
| YouTubeXL | Yes |
| Browser Detail | HTML 5 |
| Fan | No |
| Power Usage Standby | 12V ２A |
| W (mm) | 160 |
| D (mm) | 115 |
| H (mm) | 25 |
| Volume (litre) | 0.46 |
